Reciprocating Air Compressors

  • Home
  • Reciprocating Air Compressors

We are Dealer, Distributor, Supplier, Exporter of Reciprocating Air Compressors, KND, Sadguru, MEC, ELGI and our setup is situated in Karad, Maharashtra, India.

air-compressors-1
air-compressors-2
air-compressors-3

air-compressors-4
air-compressors-5
air-compressors-6

reciprocating-air-compressors-1
reciprocating-air-compressors-2
reciprocating-air-compressors-3

APPLICATIONS :
  • Garages
  • Textile Mills
  • Sand Blasting
  • CNC Machine Shops
  • Operating Pneumatic Tools
  • Cleaning
FEATURES :
  • Each part is precision machined for high efficiency and durability.
  • Deep finned cast iron cylinders, heads, Aluminium intercooler and after cooler pipes ensure efficient cooling under continuous operations.
  • Crankshaft and connecting rod are made of forged alloy steel and hardened for good wear resistance.
  • The compressor has a splash type lubrication and provided with a oil level indicator.
  • Flywheel is dynamically balanced for long bearing life and vibration free running.
  • Air filters are of efficient design and finger plate type valves are provided for easy flow and maintenance.
  • Air receivers are made of heavy gauge mild steel and hydraulically tested. hand holes are provided for easy cleaning and maintenance in big size receivers.
  • Non - return valves are robust in construction and are provided with viton seals.
          Working Pressure Tank size Approx. Weight W/o motor in kg
Model no. Motor HP No.of Piston R.P.M. Piston C.F.M. P.S.I. kg/cm2 Inch Ltr
SE 2 0.5 1 720 2.8 75 5   36 35
SE 4 S 1 1 720 3.5 100 7   35 45
SE 4  1 1 720 3.5 100 7   60 50
SE 4 A 1 1 720 3.5 100 7   80 60
SE 4 A 1 1 720 3.5 100 7   100 70
SE 6 B 1 2 720 5.2 100 7   100 75
SE 8 V 2 2 720 10 120 8   160 110
SE 8 V 2 2 720 10 120 8   200 135
SE 10 V 3 2 720 13 130 9   200 140
SE 242 5 2 720 17 175 12   220 150
SE 253 7.5 2 720 26 175 12   250 200
SE 71 T 10 2 720 40 175 12   300 300
SE 15T 15 3 720 63 175 12   500 500
